Cast-resin Dry-type Transformer

Product Overview

It is a high strength FRP structure by using Swiss Ciba-Geigy epoxy resin as insulating material and adopting German HEDRICH vacuum casting equipment to cast epoxy resin in vacuum and curing. The high-voltage coil is wound by copper wire and vacuum cast molding, while the low-voltage coil is wound by copper foil. It has the characteristics of good electrical performance, strong lightning shock resistance, strong short circuit resistance, small size and light weight. Temperature display controller can be installed to display and control the operating temperature of transformer winding to ensure the normal service life of transformer.

Product Characteristics

• High mechanical strength, low partial discharge and high reliability.
• Flame retardant, explosion-proof, no environmental pollution.
• High level of short circuit resistance and lightning impact.
• Axial flow fan is adopted, which has low noise and uniform cooling.
• Balanced ampere turns of coil, small magnetic flux leakage at end and good short-circuit impact resistance.
• Compact structure and small size.
• Good manufacturability, uniform voltage arrangement and high reliability.
• The coil has uniform temperature distribution along the axial direction, with good heat dissipation effect.

Technical Parameters
